Busbar Punching Tool CH-100B
Busbar Punching Tool CH-100B-1

Busbar Punching Tool CH-100B

 Model:CH-100B
♦ It is designed for punching holes on CU/Al busbar.
♦ Fast speed punching, accurate position without deviation.
♦ Portable unit could be taken to site or fixed in factory for batch punching work.
♦ Hydraulic punching could avoid cutting scraps while punching hole, It ismuch safer and clearer while operation.
♦ All the other size(shape) dies can be customised according to the request.
♦ Match pump CFP-800-1, CP-700, DYB-63A or electrical pump.
